R900965477 DBW10A1-5X/315-6EG24N9K4 Rexroth Germany Electromagnetic Relief Valve

Frequently Asked Questions (FAQ)

Q1: What is the difference between DB10 and DBW10?

DB is a pilot relief valve only — limits system pressure. DBW adds an integrated directional solenoid valve: when energized the main stage is unloaded (P→T open, near 0 bar); when de-energized it works as a normal relief valve at the set pressure.

Q2: What does "A1" mean?

"A" = subplate mounting version (NG10). "1" = adjustment type = hexagon socket with protective cap (Allen key adjustable). This is the most common adjustment style for DB/DBW Size 10.

Q3: How do I adjust the relief pressure?

With system depressurized, remove the protective cap, turn the setscrew with an Allen key — clockwise to increase, counterclockwise to decrease. Factory preset is typically near minimum of the spring range. Reinstall the cap and verify with a pressure gauge. The solenoid does NOT alter the set pressure — it only enables/unloads.

Q4: What is the solenoid logic — energized = relief or unload?

Standard: Solenoid DE-energized = relief active​ at set pressure. Solenoid ENERGIZED = system unloaded​ (P connected to T, pressure drops to near tank pressure). Confirm this matches your application's control logic before wiring.

Q5: Which subplate and electrical connector are needed?

• Subplate: standard NG10 (ISO 6264)​ with P and T ports (G 1/2" or M18×1.5 on subplate), four M10 bolts @ ~35–40 N·m.

• Electrical: EN 175301-803 Form A (DIN 43650-A) 3-pin + PE connector (K4 mating plug), 24 V DC. If the plug has an LED indicator, observe (+) / (–) polarity markings on the plug.

Q6: Common faults & causes?

• Solenoid clicks but system does NOT unload:​ pilot orifice clogged, main spool stuck, no coil current (check ~18–28 Ω coil resistance), manual override jammed.

• Pressure won't reach set value / creeps early:​ wrong spring grade (not /315), pilot damping hole blocked, contaminated pilot seat, excessive T-backpressure (internal pilot drain).

• Coil overheats / burnt smell:​ overvoltage (>10% above 24V), wrong voltage coil fitted, or mechanical damage — replace only with correct G24 wet-pin coil.

• Chatter / unstable:​ air in system, high T-backpressure, worn pilot seat — bleed air first.

Q7: Does T-port backpressure affect set pressure?

Yes — this model has internal pilot drain. Backpressure at T adds 1:1 to the relief setpoint. If your tank line has >5 bar sustained backpressure, consider the DBW…Y version (external pilot drain to separate tank line).

Q8: Fluid & seal compatibility?

NBR seals = mineral oil (HL/HLP) & HFC (water-glycol). For HEES/HETG biodegradable oils or HFD phosphate ester → specify FKM (Viton) seal variant. Maintain oil cleanliness per ISO 4406 code 18/16/13 or better.
