119-5407、497-8499、114-0602 CAT excavator main pump (20-36 tons) plunger hydraulic motor adapted for 320D/D2/323D2/326GC/329D/330D/336D/D2XE

119-5407、497-8499、114-0602 CAT excavator main pump (20-36 tons) plunger hydraulic motor adapted for 320D/D2/323D2/326GC/329D/330D/336D/D2XE
119-5407、497-8499、114-0602 CAT excavator main pump (20-36 tons) plunger hydraulic motor adapted for 320D/D2/323D2/326GC/329D/330D/336D/D2XE 119-5407、497-8499、114-0602 CAT excavator main pump (20-36 tons) plunger hydraulic motor adapted for 320D/D2/323D2/326GC/329D/330D/336D/D2XE

Large Image :  119-5407、497-8499、114-0602 CAT excavator main pump (20-36 tons) plunger hydraulic motor adapted for 320D/D2/323D2/326GC/329D/330D/336D/D2XE

Product Details:
Place of Origin: USA
Brand Name: CAT
Certification: ISO
Model Number: 119-5407、497-8499、114-0602
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: wooden box
Delivery Time: 2 weeks
Payment Terms: MoneyGram,Western Union,T/T,D/P,D/A,L/C
Supply Ability: 100
Contact Now

119-5407、497-8499、114-0602 CAT excavator main pump (20-36 tons) plunger hydraulic motor adapted for 320D/D2/323D2/326GC/329D/330D/336D/D2XE

Description
Outlet Port Position: Top, Side, Bottom (customizable Angle: 0°/90°/180°) Shaft Specification: Shaft Diameter: 14–50 Mm; Keyway Type: Flat Key, Splined Key (14–28 Teeth)
Control Mode: Manual Control, Hydraulic Proportional Control, Electric Proportional Control (PLC) Applicable Pump Types: Application Notes
Parameter Category: Customizable Options Displacement Range: 8.2–280 Cc/r (adjustable For Variable-displacement Pumps)
Highlight:

CAT excavator main hydraulic pump

,

plunger hydraulic motor for 320D

,

Carter hydraulic pump with warranty

119-5407, 497-8499, 114-0602 CAT Excavator Main Pump (20-36 Tons) Plunger Hydraulic Motor
Product Overview

Axial piston hydraulic main pump designed for CAT excavators in the 20-36 ton range. Compatible with models including 320D/D2, 323D2, 326GC, 329D, 330D, 336D, and D2XE.

119-5407、497-8499、114-0602 CAT excavator main pump (20-36 tons) plunger hydraulic motor adapted for 320D/D2/323D2/326GC/329D/330D/336D/D2XE 0
Compatible Pump Models by Equipment Class
Pump Type OEM Part Number Applicable Equipment Model
Axial Piston Pump 487-6207 301.5/301.6/301.7CR
Axial Piston Pump 423-0097 305.5E/306E/307E
Axial Piston Pump 272-6959 325D/329D/DL
Axial Piston Pump 369-9655 374F/390F
Axial Piston Pump 307-3063 415F/416F/422F
Gear Pump (Pilot) 560-0886 Full Range Excavators
Axial Piston Pump 295-9426 349 Series
Complete Pump Compatibility Reference
Small Excavators (3-10 Tons)
  • Main Pumps: 423-0097, 397-3941, 214-1091, 4I-1023, 348-7627, 7Y-4002, 247-7867, 358-5004
  • Compatible Models: 305.5E, 306E, 307D, 308E, 312D, 317, etc.
  • Pilot/Gear Pumps: 126-2016, 284-3536
Medium Excavators (20-36 Tons)
  • Main Pumps: 272-6959, 289-7917, 272-6955, 259-0815/10 R-8707, 451-9302, 341-2860, 567-9721, 593-8367, 436-6669, 438-1293, 244-8479, 272-6957, 339-0513, 123-2233, 126-2073, 119-5407, 497-8499, 114-0602, 0R-8102
  • Compatible Models: 320D/D2, 323D2, 326GC, 329D, 330D, 336D/D2XE, etc.
  • Rotary Pumps: 204-4916, 204-4922
  • Pilot/Gear Pumps: 175-6253, 397-6960
Large Excavators (Over 37 Tons)
  • Main/Rotary Pumps: 369-9655, 593-3840, 584-0380, 627-1304, 295-9426, 550-4341, 194-8259, 361-0718, 353-5691, 362-8488, 510-7950
  • Compatible Models: 336GC, 340, 345, 349, 374F, 385, 390F, 395GC, etc.
  • Pilot/Gear Pumps: 564-9801, 234-4638
Frequently Asked Questions
What is the part number for the main pump of Cat 320D?
Common main pump part numbers for Cat 320D include 272-6955 and HPV145 (OEM collaboration model).
How to store a spare Cat hydraulic pump?
Store the pump in a clean, dry, and ventilated area, seal all ports to prevent contamination, and avoid placing heavy objects on it.
What is the difference between a fixed-displacement and variable-displacement Cat pump?
Fixed-displacement pumps deliver a constant flow rate at a given speed, while variable-displacement pumps adjust flow based on system demand, improving energy efficiency.
What causes a hydraulic pump to lose pressure?
Pressure loss is caused by internal pump wear, leaking seals, a faulty relief valve, or air in the hydraulic system.
Are Cat hydraulic pumps compatible with biodegradable hydraulic oil?
Yes, but only if the oil meets Cat's specifications and is compatible with the pump's seal materials; consult a dealer for recommendations.
