R901430258 2WFCE40S500L-1X/M/24G1 Proportional flow control valve from Rexroth, Germany

R901430258 2WFCE40S500L-1X/M/24G1 Proportional flow control valve from Rexroth, Germany
R901430258 2WFCE40S500L-1X/M/24G1 Proportional flow control valve from Rexroth, Germany

Large Image :  R901430258 2WFCE40S500L-1X/M/24G1 Proportional flow control valve from Rexroth, Germany

Product Details:
Place of Origin: Germany
Brand Name: Rexroth
Certification: ISO
Model Number: R901430258 2WFCE40S500L-1X/M/24G1
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: wooden box
Delivery Time: 2 weeks
Payment Terms: Western Union,T/T,D/P,D/A,L/C
Supply Ability: 100
Contact Now

R901430258 2WFCE40S500L-1X/M/24G1 Proportional flow control valve from Rexroth, Germany

Description
Command Signal​: 4–20 MA (Analog Input, Corresponds To 0–100% Valve Opening) Seal Material​: NBR (Standard For Mineral Oils)
Hydraulic Fluid​: Mineral Oils (HL, HLP), HETG, HEES, HFDU Operating Temperature​: -20°C To +60°C
Weight​: Approx. 7.4 Kg
Highlight:

Rexroth proportional flow control valve

,

Rexroth hydraulic valve with warranty

,

Germany Rexroth flow control valve

Parameter

Specification

Manufacturer / Series​

Rexroth 2WFCE Series

Order Code​

R901430258

Full Model​

2WFCE40S500L-1X/M/24G1

Valve Type​

Pilot-Operated Proportional Directional Cartridge Valve (2-way, 2-position)

Primary Function​

High-flow proportional throttling / flow control; can be used as a directional valve.

Control Type​

Proportional solenoid with Integrated Electronics (OBE)​ and position feedback.

Nominal Size​

NG 40 (Cartridge size per ISO 7368)

Max. Operating Pressure​

420 bar (Ports A, B)

Rated Flow (Qn)​

500 L/min

Flow Characteristic​

Linear (L)

Pressure Compensation​

No (Requires external pressure compensator for load-independent flow control).

Ports​

A, B, X (Pilot), Y (Drain)

Mounting​

Cartridge Insert (Cavity per ISO 7368)

Electrical Connection​

12-pin connector (11+PE) per EN 175201-804

Supply Voltage​

24 V DC (Integrated electronics, no external amplifier needed)

Command Signal​

4–20 mA (Analog input, corresponds to 0–100% valve opening)

Seal Material​

NBR (Standard for mineral oils)

Hydraulic Fluid​

Mineral oils (HL, HLP), HETG, HEES, HFDU

Operating Temperature​

-20°C to +60°C

Weight​

Approx. 7.4 kg

Country of Origin​

Germany

R901430258 2WFCE40S500L-1X/M/24G1 Proportional flow control valve from Re</p> <table style= R900760386 2FRE10-4X/16LBK4V R900959337 2FRE10-4X/16LK4M R900976050 2FRE10-4X/16LK4V R900245908 2FRE10-4X/16QBK4M R900768728 2FRE10-4X/16QK4M R900915820 2FRE10-4X/25LBK4M R900249888 2FRE10-4X/25LBK4V R900932728 2FRE10-4X/25LK4M R900962961 2FRE10-4X/25QBK4M R900948692 2FRE10-4X/25QK4M R900764820 2FRE10-4X/2QEBK4M R900963481 2FRE10-4X/2QEK4M R900915815 2FRE10-4X/50LBK4M R901021448 2FRE10-4X/50LBK4V R900915813 2FRE10-4X/50LK4M R900244809 2FRE10-4X/50LK4V R900931237 2FRE10-4X/5LBK4M R900942938 2FRE10-4X/5LK4M R900962409 2FRE10-4X/5LK4V R900946937 2FRE10-4X/5QBK4M R900964806 2FRE10-4X/5QEBK4M R900962277 2FRE10-4X/5QEK4M R900915823 2FRE10-4X/60LBK4M R900976616 2FRE10-4X/60LBK4V R900915821 2FRE10-4X/60LK4M R900973066 2FRE10-4X/60LK4V R900915819 2FRE16-4X/100LBK4M R900785982 2FRE16-4X/100LBK4V R900915822 2FRE16-4X/100LK4M R900721995 2FRE16-4X/100LK4V R900927478 2FRE16-4X/125LBK4M R901040916 2FRE16-4X/125LBK4V R900915824 2FRE16-4X/125LK4M R900915814 2FRE16-4X/160LBK4M R900747708 2FRE16-4X/160LBK4V R900915816 2FRE16-4X/160LK4M R900973515 2FRE16-4X/160LK4V R900962297 2FRE16-4X/60LBK4M R900927479 2FRE16-4X/80LBK4M R901070659 2FRE16-4X/80LBK4V R900915818 2FRE16-4X/80LK4M R900734638 2FRE16-4X/80LK4V R900937860 2FRE6A-2X/10QK4MV R900937866 2FRE6A-2X/10QK4RV R900937864 2FRE6A-2X/16QK4MV R900958063 2FRE6A-2X/16QK4RV R900770641 2FRE6A-2X/1LK4MV R900960170 2FRE6A-2X/1LK4RV R900937865 2FRE6A-2X/25QK4MV R900937883 2FRE6A-2X/25QK4RV R900961336 2FRE6A-2X/2LK4MV R900245015 2FRE6A-2X/2LK4RV R900960182 2FRE6A-2X/2QEK4MV R900962992 2FRE6A-2X/2QEK4RV R900950857 2FRE6A-2X/3QK4MV R900937867 2FRE6A-2X/3QK4RV R900973053 2FRE6A-2X/6QK4MV R900956195 2FRE6A-2X/6QK4RV R900967793 2FRE6A-2X/8LK4MV R900975322 2FRE6A-2X/8LK4RV

Frequently Asked Questions (FAQ)

Q1: What is the key difference between the 2WFCE series and the 2FRE series?

A:​ The 2WFCE​ is a cartridge-style, pilot-operated valve​ designed for very high flow (500 L/min) and high pressure (420 bar). It is installed in a manifold cavity. The 2FRE​ is a subplate-mounted, direct-operated valve​ typically used for lower flow applications. The 2WFCE also features Integrated Electronics (OBE), meaning the amplifier is built into the valve cover.

Q2: Does this valve include built-in pressure compensation?

A:​ No.​ The 2WFCE40S500L is a proportional directional/throttling valve. It does not​ have a built-in pressure compensator. To achieve load-independent flow control, you must install a separate pressure compensator​ (e.g., an FD-type pressure compensator) upstream or downstream of this valve.

Q3: What does the "24G1" suffix indicate?

A:​ 24G1​ specifies the electrical interface:

  • 24: 24 V DC supply voltage.

  • G1: Analog command input of 4–20 mA​ (current signal). This interface also provides a "Ready" signal output for monitoring the valve's electronic status.

Q4: What happens if power is lost or the cable breaks?

A:​ The valve has a fail-safe closed​ function. If the supply voltage fails or drops below the threshold, or if the solenoid cable breaks, the main stage spool is pushed to its seat by spring force and system pressure, blocking flow between ports A and B.

Q5: What is the purpose of the X and Y ports?

A:​ Port X​ is the pilot supply​ port. It must be connected to a pressurized oil source (often from port A or B, or an external source) to operate the pilot stage. Port Y​ is the drain port​ for the pilot control oil and must be connected directly to the tank with minimal backpressure.
