Rexroth DBDS10K1X/200 Plug-In Relief Valve - Key Parameters

Rexroth DBDS10K1X/200 Valve - FAQ

Q1: What is the main function of this valve?

A:​ This is a direct-acting, adjustable pressure relief valve. Its primary function is to limit the maximum pressure in a hydraulic circuit by opening to divert excess flow to the tank, thereby protecting system components from overpressure.

Q2: What does the "/200" suffix in the part number mean?

A:​ The /200suffix indicates the valve's factory-set pressure. In this case, it is preset to 200 bar. The pressure can typically be manually readjusted within the valve's rated range (5-400 bar) if needed for a specific application.

Q3: How is the valve installed?

A:​ It is installed as a plug-in cartridge valve. It screws into a standard NG10 (CETOP 5) threaded cavity (M22 x 1.5) in a hydraulic manifold, valve block, or subplate. This design simplifies installation, maintenance, and replacement.

Q4: What are the key operating specifications?

A:​ The valve has a maximum operating pressure of 400 bar. Its typical maximum flow capacity is up to 60 liters per minute. The pressure setting is adjustable within a range of 5 to 400 bar. The main body is constructed from steel.

Q5: What are typical applications for this valve?

A:​ It is commonly used as a main system relief valve, a safety valve for a pump, or a branch circuit relief valve in various industrial and mobile hydraulic systems where reliable pressure control and protection are required.

Q6: Where can I find complete technical data?

A:​ For detailed installation dimensions, performance curves, and full specifications, please consult the official product documentation for order code R900424149.
