A4VSO71EO2/30L-PPB13N00 Piston Pump for Mining Loader Hydraulic System – Rexroth – Germany

A4VSO71EO2/30L-PPB13N00 Piston Pump for Mining Loader Hydraulic System – Rexroth – Germany
A4VSO71EO2/30L-PPB13N00 Piston Pump for Mining Loader Hydraulic System – Rexroth – Germany

Large Image :  A4VSO71EO2/30L-PPB13N00 Piston Pump for Mining Loader Hydraulic System – Rexroth – Germany

Product Details:
Place of Origin: Germany
Brand Name: Rexroth
Certification: ISO
Model Number: A4VSO71EO2/30L-PPB13N00
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Wooden box
Delivery Time: 2 weeks
Payment Terms: Western Union,T/T,D/P,D/A,L/C
Supply Ability: 100
Contact Now

A4VSO71EO2/30L-PPB13N00 Piston Pump for Mining Loader Hydraulic System – Rexroth – Germany

Description
Model: A4VSO71EO2/30L-PPB13N00 Displacement (Vg Max): 71 Cm³/rev
Nominal Pressure: 350 Bar (35 MPa) Rotation: L – Left-hand (viewed From Shaft End)
Weight (approx.): ≈ 53 Kg

A4VSO71EO2/30L-PPB13N00 Piston Pump for Mining Loader Hydraulic System – Rexroth – Germany
Product Overview

The A4VSO71EO2/30L-PPB13N00 is an axial piston variable displacement pump from the Rexroth A4VSO Series 30, manufactured in Germany, and engineered for open-circuit hydrostatic drives in heavy-duty mobile and industrial equipment—including mining loader hydraulic systems. It uses a swash plate design where output flow is proportional to drive speed and displacement, with stepless adjustment via swash plate angle.

The EO2 control is an electro-proportional displacement control: an external analog signal (typically ±10 V or 4-20 mA via a proportional amplifier with LVDT feedback) sets the swash plate angle and therefore the pump flow, which allows PLC- or CAN-based controllers on modern mining loaders to schedule lift, steer, and brake flows precisely. Rated at 350 bar nominal / 400 bar peak, it is built for continuous duty under shock loads, dust, and wide temperature swings typical of underground and surface mining.

Technical Specifications (Size 71, Series 30)
Parameter Specification
Model A4VSO71EO2/30L-PPB13N00
Series A4VSO Series 30 (swash plate, open circuit)
Displacement (Vg max) 71 cm³/rev
Nominal Pressure 350 bar (35 MPa)
Peak Pressure 400 bar (40 MPa)
Maximum Speed ≈ 2200 rpm (size 71, dependent on suction conditions)
Flow @ 2200 rpm ≈ 156 L/min (theoretical)
Flow @ 1500 rpm ≈ 107 L/min (theoretical)
Power @ 350 bar / 2200 rpm ≈ 91 kW
Power @ 350 bar / 1500 rpm ≈ 62 kW
Torque @ 350 bar ≈ 395 Nm
Rotation L - Left-hand (viewed from shaft end)
Control EO2 - Electro-proportional displacement control (external electric command, high pilot pressure type)
Shaft P - DIN metric parallel keyed shaft (DIN 6885)
Seals P - NBR with FKM shaft seal (standard for mineral oil)
Mounting Flange B - ISO 4-bolt metric
Ports 13 - SAE B pressure + SAE S suction, side 90° offset, metric bolts
Through-drive N00 - No auxiliary pump, no through-drive shaft
Fluid Mineral oil (HLP), HFC fluids (under reduced data, sizes 180-355 primarily)
Cleanliness NAS 1638 Class 9 / ISO 4406 18/16/13 recommended
Weight (approx.) ≈ 53 kg
A4VSO71EO2/30L-PPB13N00 axial piston pump
Model Code Breakdown

A4VSO - Axial piston variable pump, open circuit, swash plate design

71 - Nominal displacement 71 cm³/rev

EO2 - Electro-proportional displacement control, high pilot pressure type (external signal sets flow)

30 - Series 30 construction

L - Left-hand rotation

PPB13N00 - P: NBR+FKM seals; P: parallel key shaft; B: ISO 4-bolt flange; 13: SAE side-offset ports; N00: no through-drive / no aux pump

Key Features
  • Made in Germany - Rexroth German production; original label, test sheet, and COO available on request.
  • EO2 Remote Flow Command - Flow set by ±10 V / 4-20 mA; no mechanical lever or hydraulic pilot needed for basic proportionality; integrates with loader ECU/PLC.
  • Mining-Loader Ready - Short control response time, excellent suction characteristics, low noise, robust roller bearings for shock-load cycles.
  • 350 bar Continuous Duty - Hardened cylinder block, heavy-duty bearings, optimized port geometry for dusty suction conditions.
  • Swash Plate Variable Displacement - Infinitely variable flow, visual swivel angle indicator included.
  • Modular A4VSO Platform - Same mounting envelope as DR/DFR/LR controls for easy retrofit on existing loader power packs.
  • Through-Drive Body (N00 base) - Base variant without tandem shaft; tandem versions exist under other suffixes for combined steering + lift circuits.
Why Used in Mining Loader Hydraulic Systems

Modern mining loaders (LHD - Load-Haul-Dump units, underground scoops, surface wheel loaders) require:

  • Precise electronic flow split between boom, bucket, steering, and brake cooling circuits → EO2 enables ECU to command each pump electronically.
  • High pressure (350 bar) with variable flow to reduce engine throttling and heat generation during idle/hold.
  • Left-hand rotation (L) matched to specific gearbox input orientation on popular loader drivelines.
  • PPB13N00 SAE side ports for straightforward hose routing in tight engine compartments.
  • German-origin reliability for 24/7 underground operation where downtime cost is high.
Other Typical Applications
  • Underground Mining Equipment - LHD loaders, roof bolters, feeder breakers, TBM aux circuits
  • Surface Mining - Wheel loader auxiliary pumps, shovel lubrication hydraulics, crusher power packs
  • Construction & Quarry - Excavator auxiliary circuits, crusher mobile skids, screen vibrator hydraulics
  • Industrial Automation - Test benches, CNC flow-programmed cells, press feeding systems
  • Marine & Ports - Deck machinery power packs with PLC flow scheduling
Quality Assurance & Packaging
  • Origin: Sourced from Rexroth Germany production channels; pre-shipment pressure/flow/leak test performed.
  • Export Packaging: Fumigation-free wooden crate, VCI anti-rust film, corner protectors.
  • Docs: Commercial Invoice, Packing List, Certificate of Origin, factory test report.
  • Warranty: 12 months against manufacturing defects.
Countries Available for Sale

We export genuine A4VSO71EO2/30L-PPB13N00 - Made in Germany worldwide. Active sales/export coverage includes:

  • Europe: Germany, France, Italy, Spain, United Kingdom, Netherlands, Belgium, Switzerland, Austria, Poland, Czech Republic, Turkey, Sweden, Finland
  • Asia-Pacific: China, India, Japan, South Korea, Malaysia, Thailand, Vietnam, Indonesia, Singapore, Australia, New Zealand
  • Americas: United States, Canada, Mexico, Brazil, Argentina, Chile, Colombia
  • Middle East: UAE, Saudi Arabia, Qatar, Kuwait, Oman, Israel
  • Africa: South Africa, Egypt, Nigeria, Kenya, Morocco

Incoterms: EXW / FOB / CIF / DDP.

Freight: DHL/FedEx/UPS for single-unit urgent orders; LCL/FCL sea for project batches. Full export docs provided.

Frequently Asked Questions
Q: Is the A4VSO71EO2/30L-PPB13N00 made in Germany?
A: Yes. This configuration is produced in Rexroth Germany facilities. We provide original label photos, test report, and COO on request.
Q: What does EO2 control require to work on a mining loader?
A: EO2 needs an external proportional amplifier receiving ±10 V or 4-20 mA command plus a pilot pressure source (higher than EO1). The pump includes LVDT feedback; system relief valve is still mandatory for pressure limiting.
Q: Can EO2 replace a DR or DFR pump mechanically on the same loader?
A: If displacement (71), rotation (L), shaft (P), flange (B), and ports (13) match, the pump mounts identically. Control behavior changes from pressure/flow-pilot to electric-signal flow command—loader software/PLC must be updated for EO2.
Q: Does PPB13N00 mean SAE or metric ports?
A: Code 13 = SAE B (pressure) and SAE S (suction) flanges on side, 90° offset, with metric mounting bolts. Adaptors to ORFS/NPT are common but not built-in.
Q: Lead time?
A: Stock units 1-3 working days; non-stock 1-2 weeks depending on quantity.
