R901392496 3DREE16P-7X/250XYG24K31/F1V Rexroth proportional pressure reducing valve

R901392496 3DREE16P-7X/250XYG24K31/F1V Rexroth proportional pressure reducing valve
R901392496 3DREE16P-7X/250XYG24K31/F1V Rexroth proportional pressure reducing valve

Large Image :  R901392496 3DREE16P-7X/250XYG24K31/F1V Rexroth proportional pressure reducing valve

Product Details:
Place of Origin: Germany
Brand Name: Rexroth
Certification: ISO
Model Number: R901392496 3DREE16P-7X/250XYG24K31/F1V
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: wooden box
Delivery Time: 2 weeks
Payment Terms: Western Union,D/P,D/A,L/C,T/T
Supply Ability: 100
Contact Now

R901392496 3DREE16P-7X/250XYG24K31/F1V Rexroth proportional pressure reducing valve

Description
Weight​: 9.8 Kg Port Interface​: ISO 4401-07-07-0-05 (CETOP 3)
Hydraulic Fluid​: Mineral Oils (HL, HLP), Biodegradable Fluids (HETG, HEES, HEPG), And HFDU Fluids. Max. Flow Rate​: 300 L/min (for NG16 Size)
Max. Adjustable Pressure​: 250 Bar (as Per Code "250")
Highlight:

Rexroth proportional pressure reducing valve

,

Hydraulic valve 3DREE16P-7X

,

Rexroth valve 250XYG24K31/F1V

Parameter Category

Parameter

Specification / Description

General Information​

Manufacturer / Model​

Rexroth, Type 3DREE

Part Number​

R901392496

Valve Type​

3-way Proportional Pressure Reducing Valve (Pilot Operated)

Primary Function​

Pressure Reduction (P→A) & Relief/Limiting (A→T)

Hydraulic Performance​

Max. Operating Pressure​

315 bar

Max. Adjustable Pressure​

250 bar (as per code "250")

Max. Flow Rate​

300 L/min (for NG16 size)

Port Size​

NG16

Electrical & Control​

Supply Voltage​

24 VDC (Code: G24)

Command Signal​

4 ~ 20 mA (Code: F1)

Electronics​

On-Board Electronics (OBE, Integrated Amplifier)

Electrical Connector​

7-pin plug (DIN EN 175201-804, Code: K31)

Installation & Ports​

Mounting Style​

Subplate mounting

Port Interface​

ISO 4401-07-07-0-05 (CETOP 3)

Main Ports​

P, A, B, T

Pilot Supply​

Pilot Supply Type​

External Supply (Code: XY)​ – Port X for external pilot pressure, Port Y to tank.

Pilot Drain​

Must be connected to tank with zero backpressure.

Media & Environment​

Hydraulic Fluid​

Mineral oils (HL, HLP), biodegradable fluids (HETG, HEES, HEPG), and HFDU fluids.

Seal Material​

FKM (Viton) (Code: V)

Weight​

Approx. 9.8 kg

R901392496 3DREE16P-7X/250XYG24K31/F1V Rexroth proportional pressure reducing valve 0

R900954427 3DREPE6C-2X/25EG24K31/A1M
R900973913 3DREPE6C-2X/25EG24K31/F1M
R900955853 3DREPE6C-2X/25EG24K31/F1V
R900955784 3DREPE6C-20/25EG24N9K31/A1M
R900954427 3DREPE6C-2X/25EG24K31/A1M
R900954428 3DREPE6C-2X/45EG24K31/A1M
R900700593 3DREPE6C-2X/16EG24N9K31/A1V
R901094369 3DREPE6C-2X/45EG24K31/A1V
R901015676 3DREPE6C-2X/16EG24N9K31/A1M
R901076954 3DREPE6B-2X/25EG24N9K31/F1M
R901060431 3DREPE6B-2X/45EG24K31/A1M
R901051881 3DREPE6A-2X/45EG24N9K31/A1M
R901033013 3DREPE6A-2X/25EG24N9K31/F1M
R901016018 3DREPE6B-2X/45EG24N9K31/A1M
R900956101 3DREP6C-20=25EG24N9K4/M=00
R900955784 3DREPE6C-2X/25EG24N9K31/A1M
R900925484 3DREPE6C-2X/25EG24N9K31/A1V
R900958848 3DREPE6C-2X/25EG24N9K31/F1M
R900926984 3DREPE6C-2X/25EG24N9K31/F1V
R900958788 3DREPE6C-20=25EG24N9K31/A1M=00
R901010402 3DREPE6A-20=25EG24N9K31/A1M=00
R900958788 3DREPE6C-20=25EG24N9K31/A1M=00
R901010402 3DREPE6A-20=25EG24N9K31/A1M=00
R900956101 3DREP6C-20=25EG24N9K4/M=00
R900955784 3DREPE6C-2X/25EG24N9K31/A1M
R900954425 3DREPE6C-2X/16EG24K31/A1M
R900975912 3DREPE6A-2X/25EG24N9K31/F1V
R900954424 3DREPE6A-2X/45EG24K31/A1M
R900954423 3DREPE6A-2X/25EG24K31/A1M
R900925013 3DREPE6B-2X/45EG24N9K31/A1V
R900954425 3DREPE6C-2X/16EG24K31/A1M
R900954427 3DREPE6C-2X/25EG24K31/A1M
R900931050 3DREPE6B-2X/25EG24N9K31/A1V
R900925484 3DREPE6C-2X/25EG24N9K31/A1V
R900929865 3DREPE6B-2X/45EG24N9K31/A1V=LB
R900954428 3DREPE6C-2X/45EG24K31/A1M
R900954428 3DREPE6C-2X/45EG24K31/A1M
R900970698 3DREPE6C-2X/45EG24N9K31/F1V
R900954422 3DREPE6A-2X/16EG24K31/A1M
R900954423 3DREPE6A-2X/25EG24K31/A1M
R900975912 3DREPE6A-2X/25EG24N9K31/F1V
R900700593 3DREPE6C-2X/16EG24N9K31/A1V
R900955887 3DREP6C-21=25EG24N9K4/M
R900955803 3DREP6A-2X/25EG24N9K4/M
R900955796 3DREP6C-2X/45EG24N9K4/M
R900954422 3DREPE6A-2X/16EG24K31/A1M
R900954423 3DREPE6A-2X/25EG24K31/A1M
R900954424 3DREPE6A-2X/45EG24K31/A1M
R900954425 3DREPE6C-2X/16EG24K31/A1M
R900956101 3DREP6C-20=25EG24N9K4/M=00
R900958788 3DREPE6C-20=25EG24N9K31/A1M=00
R901010402 3DREPE6A-20=25EG24N9K31/A1M=00
R900958848 3DREPE6C-2X/25EG24N9K31/F1M
R900926984 3DREPE6C-2X/25EG24N9K31/F1V
R900954424 3DREPE6A-2X/45EG24K31/A1M
R901051881 3DREPE6A-2X/45EG24N9K31/A1M
R900978110 3DREPE6A-2X/45EG24N9K31/F1M
R901060430 3DREPE6B-2X/16EG24K31/A1M
R900956182 3DREPE6B-2X/25EG24K31/A1M
R900955862 3DREPE6B-2X/25EG24N9K31/A1M
R900931050 3DREPE6B-2X/25EG24N9K31/A1V
R900925013 3DREPE6B-2X/45EG24N9K31/A1V
R900929865 3DREPE6B-2X/45EG24N9K31/A1V=LB
R900573750 3DREP6C-1X/25A24N9K4V
R900551330 3DREP6C-1X/25A24NK4V
R900498485 3DREP6C-1X/25A12NK4M
R900494199 3DREP6A-1X/45A24NK4M
R900494195 3DREP6B-1X/45A24NK4M
R900494193 3DREP6B-1X/45A24K4M
R900494191 3DREP6C-1X/45A24NK4M
R900494190 3DREP6C-1X/45A24NK4V
R900494171 3DREP6B-1X/25A24NK4M
R900494167 3DREP6C-1X/25A24NK4M
R900494165 3DREP6C-1X/25A24K4M
R900494163 3DREP6A-1X/16A24NK4M
R900494155 3DREP6C-1X/16A24NK4M
R900494153 3DREP6C-1X/16A24K4M
R900484840 3DREP6C-1X/16A24NJM
R900451448 3DREP6A-1X/45A24N9K4M
R900956101 3DREP6C-20=25EG24N9K4/M=00
R900954474 3DREP6A-2X/16EG24K4/M
R900954417 3DREP6A-2X/25EG24K4/M
R900954418 3DREP6A-2X/45EG24K4/M
R900954419 3DREP6C-2X/16EG24K4/M
R900954420 3DREP6C-2X/25EG24K4/M
R900954421 3DREP6C-2X/45EG24K4/M
R900550096 3DREP6C-1X/16A24N9K4M
R900547100 3DREP6C-1X/25A24N9K4M
R900498677 3DREP6A-1X/25A24NJM
R900498673 3DREP6C-1X/25A24NJM
R900498672 3DREP6C-1X/25A24JM
R900494189 3DREP6C-1X/45A24K4M
R900494175 3DREP6A-1X/25A24NK4M
R900576424 3DREP6C-1X/25A24N2JK10M
R900955887 3DREP6C-2X/25EG24N9K4/M
R900955862 3DREPE6B-2X/25EG24N9K31/A1M
R901015676 3DREPE6C-2X/16EG24N9K31/A1M
R901060430 3DREPE6B-2X/16EG24K31/A1M
R900956182 3DREPE6B-2X/25EG24K31/A1M
R901051881 3DREPE6A-2X/45EG24N9K31/A1M
R900978110 3DREPE6A-2X/45EG24N9K31/F1M
R901015676 3DREPE6C-2X/16EG24N9K31/A1M
R900954428 3DREPE6C-2X/45EG24K31/A1M
R900970698 3DREPE6C-2X/45EG24N9K31/F1V
R961000391 DICHTUNGSSATZ3DREP6.-2X/V
R961000390 DICHTUNGSSATZ3DREP6.-2X/M
R961000388 DICHTUNGSSATZ3DREP6.-1X/V
R961000330 DICHTUNGSSATZ3DREP6.-1X/M

Detailed Model Code Breakdown

The full model code 3DREE16P-7X/250XYG24K31F1Vspecifies the key configuration:

  • 3DREE: Series designation for a 3-way proportional pressure reducing valve with E​ indicating On-Board Electronics (OBE).

  • 16: Size NG16.

  • P: Subplate mounting.

  • 7X: Design version.

  • 250: The maximum electrically adjustable pressure is 250 bar.​ (Note: The valve body is rated for 315 bar, but the setting is limited to 250 bar).

  • XY: Pilot supply configuration.​ X​ = External pilot supply, Y​ = External pilot drain. This requires a separate, clean external pilot pressure source.

  • G24: 24V DC power supply.

  • K31: 7-pin electrical connector.

  • F1: Command input is a 4 ~ 20 mA current signal.

  • V: Seal material is FKM (Viton).

Key Selection and Application Notes

  1. Critical Pilot Supply:​ The XY​ version requires a stable, clean external pilot pressure source​ connected to port X, with port Y connected directly to tank (zero backpressure). If an external source is unavailable, a Y​ (internally piloted) version should be selected.

  2. Pressure Setting Limit:​ While the valve is rated for 315 bar, this specific variant is electronically limited to a maximum setting of 250 bar. For full 315 bar adjustability, select a model with code "315".

  3. Signal Compatibility:​ The valve is configured for a 4-20 mA analog current signal. If your controller outputs a 0-10 V signal, select an A1​ version.

  4. Integrated Amplifier:​ The E​ in the code signifies On-Board Electronics (OBE), meaning no external amplifier card is required. Connect power and the command signal directly.
