R901483247 Z3DREE10VP2-1X/315XLG24K31A1M Rexroth Germany proportional solenoid valve

R901483247 Z3DREE10VP2-1X/315XLG24K31A1M Rexroth Germany proportional solenoid valve
R901483247 Z3DREE10VP2-1X/315XLG24K31A1M Rexroth Germany proportional solenoid valve

Large Image :  R901483247 Z3DREE10VP2-1X/315XLG24K31A1M Rexroth Germany proportional solenoid valve

Product Details:
Place of Origin: Germany
Brand Name: Rexroth
Certification: ISO
Model Number: R901483247 Z3DREE10VP2-1X/315XLG24K31A1M
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Germany
Delivery Time: 2 weeks
Payment Terms: Western Union,T/T,D/P,D/A,L/C
Supply Ability: 100
Contact Now

R901483247 Z3DREE10VP2-1X/315XLG24K31A1M Rexroth Germany proportional solenoid valve

Description
Weight​: 3.4 Kg Electrical Connector​: 7-pin Device Plug (6+PE)
Command Signal​: 0–10 V (A1) Supply Voltage​: 24 V DC
Max. Flow​: 120 L/min
Highlight:

Rexroth proportional solenoid valve

,

Rexroth hydraulic valve with warranty

,

Germany Rexroth proportional valve

Parameter

Value / Description

Order Code​

R901483247

Type​

Proportional pressure reducing valve, pilot-operated

Function​

P2 → P1 (Reduces inlet P2 to controlled outlet P1)

Size​

NG10 (CETOP 3)

Max. Operating Pressure​

350 bar (P, A, B, X); 250 bar (T)

Max. Flow​

120 L/min

Pressure Setting​

Up to 315 bar (proportional to signal)

Mounting​

Sandwich / Stacking plate (ISO 4401-05-05-0-05)

Control​

Proportional solenoid with integrated electronics (OBE)​

Supply Voltage​

24 V DC

Command Signal​

0–10 V (A1)

Electrical Connector​

7-pin device plug (6+PE)

Seals​

FKM (Viton®)

Weight​

Approx. 3.4 kg

R901483247 Z3DREE10VP2-1X/315XLG24K31A1M Rexroth Germany proportional </p> <table style= R900955887 3DREP6C-2X/25EG24N9K4/M R900958848 3DREPE6C-21/25EG24N9K31/F1M R900958788 3DREPE6C-20=25EG24N9K31/A1M=00 R901010402 3DREPE6A-20=25EG24N9K31/A1M=00 R900954427 3DREPE6C-21/25EG24K31/A1M R900954427 3DREPE6C-2X/25EG24K31/A1M R900973913 3DREPE6C-2X/25EG24K31/F1M R900955853 3DREPE6C-2X/25EG24K31/F1V R900955784 3DREPE6C-20/25EG24N9K31/A1M R900954427 3DREPE6C-2X/25EG24K31/A1M R900954428 3DREPE6C-2X/45EG24K31/A1M R900700593 3DREPE6C-2X/16EG24N9K31/A1V R901094369 3DREPE6C-2X/45EG24K31/A1V R901015676 3DREPE6C-2X/16EG24N9K31/A1M R901076954 3DREPE6B-2X/25EG24N9K31/F1M R901060431 3DREPE6B-2X/45EG24K31/A1M R901051881 3DREPE6A-2X/45EG24N9K31/A1M R901033013 3DREPE6A-2X/25EG24N9K31/F1M R901016018 3DREPE6B-2X/45EG24N9K31/A1M R900956101 3DREP6C-20=25EG24N9K4/M=00 R900955784 3DREPE6C-2X/25EG24N9K31/A1M R900925484 3DREPE6C-2X/25EG24N9K31/A1V R900958848 3DREPE6C-2X/25EG24N9K31/F1M R900926984 3DREPE6C-2X/25EG24N9K31/F1V R900958788 3DREPE6C-20=25EG24N9K31/A1M=00 R901010402 3DREPE6A-20=25EG24N9K31/A1M=00 R900958788 3DREPE6C-20=25EG24N9K31/A1M=00 R901010402 3DREPE6A-20=25EG24N9K31/A1M=00 R900956101 3DREP6C-20=25EG24N9K4/M=00 R900955784 3DREPE6C-2X/25EG24N9K31/A1M R900954425 3DREPE6C-2X/16EG24K31/A1M R900975912 3DREPE6A-2X/25EG24N9K31/F1V R900954424 3DREPE6A-2X/45EG24K31/A1M R900954423 3DREPE6A-2X/25EG24K31/A1M R900925013 3DREPE6B-2X/45EG24N9K31/A1V R900954425 3DREPE6C-2X/16EG24K31/A1M R900954427 3DREPE6C-2X/25EG24K31/A1M R900931050 3DREPE6B-2X/25EG24N9K31/A1V R900925484 3DREPE6C-2X/25EG24N9K31/A1V R900929865 3DREPE6B-2X/45EG24N9K31/A1V=LB R900954428 3DREPE6C-2X/45EG24K31/A1M R900954428 3DREPE6C-2X/45EG24K31/A1M R900970698 3DREPE6C-2X/45EG24N9K31/F1V R900954422 3DREPE6A-2X/16EG24K31/A1M R900954423 3DREPE6A-2X/25EG24K31/A1M R900975912 3DREPE6A-2X/25EG24N9K31/F1V R900700593 3DREPE6C-2X/16EG24N9K31/A1V R900955887 3DREP6C-21=25EG24N9K4/M R900955803 3DREP6A-2X/25EG24N9K4/M R900955796 3DREP6C-2X/45EG24N9K4/M R900954422 3DREPE6A-2X/16EG24K31/A1M R900954423 3DREPE6A-2X/25EG24K31/A1M R900954424 3DREPE6A-2X/45EG24K31/A1M

FAQ: Rexroth Z3DREE10VP2-1X/315XLG24K31A1M

What is this valve?​

It is a pilot-operated proportional pressure reducing valve​ with integrated electronics (OBE). It reduces a higher inlet pressure (P2) to a precisely controlled lower outlet pressure (P1) based on an electrical command signal.

What are its key features?​

  • Integrated Electronics (OBE):​ The amplifier is built into the solenoid, simplifying wiring and setup.

  • High Pressure:​ Handles up to 350 bar inlet pressure and reduces it proportionally up to 315 bar.

  • Sandwich Mounting:​ Designed for compact installation between a directional valve and subplate.

How does it work?​

An electrical signal (0–10 V) controls the pilot solenoid. The higher the voltage, the higher the reduced outlet pressure (P1). If the signal is lost, the valve typically closes or returns to a minimal pressure.

Where is it typically used?​

Used in hydraulic systems requiring precise, variable pressure control, such as clamping circuits, press controls, or secondary circuit pressure regulation in industrial machinery.

How do I wire it?​

  • Power:​ 24V DC to the coil connector.

  • Signal:​ Connect the 0–10 V command signal to the designated pins on the integrated electronics connector.

  • Drain:​ The external drain port (Y) must be connected directly to the tank with minimal backpressure.

What if the pressure is unstable or incorrect?​

  • Check for contamination in the pilot orifice.

  • Verify the 0–10 V signal is stable and not dropping.

  • Ensure the inlet pressure (P2) is sufficiently higher than the desired reduced pressure (P1).

  • Confirm the external drain line (Y) is not blocked and has low backpressure.
