Rexroth DBDS10K1X/160E Plug-In Relief Valve - Key Parameters

Rexroth DBDS10K1X/160E Valve - FAQ

Q1: How is this valve different from the DBDS6K1X model?

A:​ The main difference is the nominal size. The DBDS10K1X is a NG10 (CETOP 5) size valve with a larger thread (M22x1.5) and a higher typical flow capacity (up to 60 l/min) compared to the NG6 (CETOP 3) DBDS6K1X model. It is designed for larger hydraulic circuits.

Q2: What does the "/160E" suffix mean?

A:​ The /160Esuffix typically indicates the valve is factory-set to a specific pressure, in this case likely 160 bar. The "E" may denote a particular variant or production code. The pressure can usually be readjusted within its standard range.

Q3: How is the valve installed?

A:​ It is installed as a plug-in cartridge. It screws into a standard NG10 (CETOP 5) threaded cavity (M22 x 1.5) in a hydraulic manifold or valve block. This design allows for easy installation, removal, and maintenance.

Q4: What are the main operating specifications?

A:​ The valve has a maximum operating pressure of 400 bar. Its pressure setting is adjustable, typically within a range of 5 to 400 bar. The typical maximum flow capacity is up to 60 liters per minute. The main body is constructed from steel.

Q5: Where can I find the complete technical data?

A:​ For detailed installation dimensions, performance curves, and full specifications, please consult the official product documentation for order code R900769414.
