R900345743 M-SR30KE02-1X/ Hydraulic System Check Valve
R900345743 M-SR30KE02-1X/ Hydraulic system check valve from Rexroth, Germany
Technical Specifications
| Parameter |
Value |
| Part Number |
R900345743 M-SR30KE02-1X/ |
| Product Type |
Check Valve, Cartridge Type |
| Product Series |
M-SR |
| Valve Spool |
Seat Design |
| Actuation Type |
Direct Acting |
| Working Pressure |
350 bar |
| Flow Rate |
300 l/min |
| Pressure Setting |
0.2 bar |
| Pressure Preset |
No |
| Hydraulic Fluid |
HL, HLP, HFC |
| Seal Material |
NBR |
| Number of Ports |
2 |
| Weight |
0.25 kg |
Related Products
R900345743 M-SR30KE02-1X/
R900347495 Z2S6-1-6X/
R900347498 Z2S6A1-6X/
R900347499 Z2S6A2-6X/
R900347501 Z2S6B1-6X/
R900407394 Z2S10-1-3X/
R900407424 Z2S10A1-3X/
R900433032 Z2S22A1-5X
R900432915 Z2S22-1-5X/
R900483371 SL10PA1-4X/M
R900052392 M-3SED6CK1X/350CG24N9K4
R900052621 M-3SED6UK1X/350CG24N9K4
R900572890 M-2SEW6P3X/420MG24N9K4
R900569808 M-2SEW6N3X/420MG24N9K4
R901290869 M-3SEW6C3X/420MG24N9Z2/B08V SO865
R900075565 M-3SEW10C1X/420MG24N9K4
R900051544 M-3SEW10U1X/630MG24N9K4
R900051053 M-3SED10UK1X/350CG24N9K4
R900944594 4WE6D6X/EG110N9K4/V
R901008688 4WE6D6X/EG220N9K4/V
R901089245 4WE6C7X/HG24N9K4
R988129092 4WE6D1X/HG24N9K4
R901108991 4WE6D7X/HG24N9K4/B10
R988129089 4WE6J1X/HG24N9K4
R901108990 4WE6J7X/HG24N9K4/B10
R988129093 4WE6Y1X/HG24N9K4
R901089243 4WE6Y7X/HG24N9K4
R900561180 3WE6A6X/EG24N9K4
R900561272 4WE6C6X/EG24N9K4
R900561274 4WE6D6X/EG24N9K4
R900915069 4WE6D6X/EG24N9K4/B10
R900561278 4WE6E6X/EG24N9K4
R900561282 4WE6G6X/EG24N9K4
R900561288 4WE6J6X/EG24N9K4
R900548271 4WE6J6X/EG24N9K4/B10
Product Overview
Highlights
The Rexroth M-SR 30 KE02-1X/ is a high-flow, low-cracking-pressure cartridge check valve designed for systems where minimizing pressure drop is critical. It features an ultra-low 0.2 bar opening pressure while maintaining a substantial 300 l/min flow capacity.
Core Specifications
- Working Pressure: 350 bar
- Flow Rate: 300 l/min
- Cracking Pressure: 0.2 bar
- Seal Material: NBR
- Fluid Compatibility: HL, HLP, HFC
- Weight: Approx. 0.25 kg
Key Features & Advantages
- Ultra-Low Opening Pressure: 0.2 bar cracking pressure minimizes system pressure loss and improves energy efficiency, ideal for low-pressure or high-sensitivity circuits.
- High Flow Capacity: Delivers 300 l/min to meet the demands of high-flow hydraulic systems.
- Robust Pressure Rating: Rated for 350 bar, ensuring reliable performance in demanding applications.
- Wide Compatibility: Compatible with common HL, HLP, and HFC hydraulic fluids.
- Standard & Compact: Direct-acting seat design and cartridge form factor for easy integration.
Typical Applications
- Industrial hydraulic systems with high efficiency requirements
- Mobile equipment circuits sensitive to pressure losses
- Hydraulic power units where minimizing pressure drop is crucial
- Any application demanding high flow with minimal flow resistance
Frequently Asked Questions
Q: What is the main difference between the KE02 and KE05 models?
A: The main difference is the cracking (opening) pressure. The KE02 model has a 0.2 bar opening pressure, while the KE05 models have a 0.5 bar opening pressure, making the KE02 more efficient in low-pressure-drop applications.
Q: What flow rate and pressure can this valve handle?
A: It can handle a flow rate of 300 l/min and a maximum working pressure of 350 bar.
Q: Why would I choose a KE02 valve over a standard model?
A: Choose the KE02 if your hydraulic circuit is highly sensitive to pressure losses or requires maximum energy efficiency, as its 0.2 bar opening pressure minimizes unwanted pressure drop.
Q: What types of seals and fluids is it compatible with?
A: It uses NBR seals and is compatible with HL, HLP, and HFC hydraulic fluids.
Q: In what type of system is this valve particularly beneficial?
A: It is especially beneficial in high-flow systems where maintaining low system pressure drop is critical, such as in energy-efficient mobile hydraulics or large industrial circuits with long pipe runs.
