PV7-1X/06-10RA01MA0-10-P65Q12 PV7-2X/20-25RA01MA0-10-P63Q35 PV7-1X/06-10RA01MA0-10-P70Q12 Rexroth blade pump German original hydraulic pump PV7 series oil pump

PV7-1X/06-10RA01MA0-10-P65Q12 PV7-2X/20-25RA01MA0-10-P63Q35 PV7-1X/06-10RA01MA0-10-P70Q12 Rexroth blade pump German original hydraulic pump PV7 series oil pump
PV7-1X/06-10RA01MA0-10-P65Q12 PV7-2X/20-25RA01MA0-10-P63Q35 PV7-1X/06-10RA01MA0-10-P70Q12 Rexroth blade pump German original hydraulic pump PV7 series oil pump PV7-1X/06-10RA01MA0-10-P65Q12 PV7-2X/20-25RA01MA0-10-P63Q35 PV7-1X/06-10RA01MA0-10-P70Q12 Rexroth blade pump German original hydraulic pump PV7 series oil pump

Large Image :  PV7-1X/06-10RA01MA0-10-P65Q12 PV7-2X/20-25RA01MA0-10-P63Q35 PV7-1X/06-10RA01MA0-10-P70Q12 Rexroth blade pump German original hydraulic pump PV7 series oil pump

Product Details:
Place of Origin: German
Brand Name: Rexroth
Certification: ISO
Model Number: PV7-1X/06-10RA01MA0-10-P65Q12 PV7-2X/20-25RA01MA0-10-P63Q35 PV7-1X/06-10RA01MA0-10-P70Q12
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: wooden box
Delivery Time: 2 weeks
Payment Terms: MoneyGram,Western Union,T/T,D/P,D/A,L/C
Supply Ability: 100
Contact Now

PV7-1X/06-10RA01MA0-10-P65Q12 PV7-2X/20-25RA01MA0-10-P63Q35 PV7-1X/06-10RA01MA0-10-P70Q12 Rexroth blade pump German original hydraulic pump PV7 series oil pump

Description
Viscosity Range: 10–1000 Mm²/s (operation); 2–1500 Mm²/s (start-up) Fluid Temperature Range: '-20 °C To +80 °C (operation); -40 °C To +90 °C (storage)
Model Series: PV7-1X/06-10RA01MA0-10-P65Q12 PV7-2X/20-25RA01MA0-10-P63Q35 PV7-1X/06-10RA01MA0-10-P70Q12 Case Drain Flow (at Rated Pressure): 1.5–2.5
Seal Material: NBR (standard); FKM (optional)
Highlight:

Rexroth PV7 hydraulic vane pump

,

German original vane pump

,

PV7 series oil pump

Rexroth PV7 Series Blade Pump
PV7-1X/06-10RA01MA0-10-P65Q12
PV7-2X/20-25RA01MA0-10-P63Q35
PV7-1X/06-10RA01MA0-10-P70Q12
Product Overview

German original hydraulic pump from the PV7 series, designed for industrial applications requiring reliable oil pump performance with pressure compensation control.

Technical Specifications
Parameter/Property Category Direct-Acting (PV7-A) Series Pilot-Operated (PV7-C/D/N/W) Series Unit Remarks
Model Range PV7-1X/06-10RA01MA0-10, PV7-2X/20-25RA01MA0-10 PV7-1X/14-20RE01MC0-16, PV7-1X/100-118RE07KD0-16 - 1X/2X=component series; 06/14/20=frame size
Displacement per Revolution 10-25 14-150 cm³/rev Displacement varies by specific model suffix
Max. Continuous Working Pressure 100 160 bar PV7-A: ≤100 bar; PV7-C/D/N/W: ≤160 bar
Max. Peak Pressure 120 200 bar Short-term (≤5s) overload only
Speed Range 600-2800 600-3600 rpm Higher speed for smaller displacement models
Max. Flow Rate (at 1800 rpm) 36 270 l/min Calculated at rated displacement
Volumetric Efficiency (Rated Condition) ≥90% ≥92% % At 160 bar, 1800 rpm, ISO VG 46 oil
Total Efficiency (Nominal Operation) ≥80% ≥82% % Includes mechanical & volumetric efficiency
Suction Pressure Range 1 -0.8 to +1 bar Absolute pressure: 0.2-1.1 bar
Fluid Compatibility Mineral oil (HLP), synthetic oil (HETG/HEES) Mineral oil (HLP), synthetic oil (HETG/HEES) - Use FKM seals for synthetic fluids
Fluid Viscosity Range 10-1000 (operation); 2-1500 (start-up) 10-1000 (operation); 2-1500 (start-up) mm²/s Optimal: 16-160 mm²/s
Fluid Temperature Range -20 to +80 -20 to +80 °C Storage: -40 to +90 °C
Noise Level (1 m Distance, Rated Operation) ≤63 ≤65 dB(A) Pilot-operated models have optimized noise reduction
Mounting Standard ISO 3019-2 flange ISO 3019-2 flange - Optional foot mounting for some models
Shaft Connection ISO 4162 splined shaft ISO 4162 splined shaft - Keyed shaft available on request
Seal Material NBR (standard); FKM (optional) NBR (standard); FKM (optional) - NBR for mineral oil; FKM for synthetic oil
Weight 8-12 10-35 kg Depends on displacement and control type
Control Type Direct-acting pressure compensation Pilot-operated pressure/flow control - PV7-A: direct-acting; PV7-C/D/N/W: pilot-operated
Response Time (Pressure Rise) 40-60 20-40 ms Faster response for pilot-operated models
Housing Material GG25 cast iron GG25 cast iron - High strength, vibration-resistant
Rotor/Stator Material 42CrMo4 alloy steel (quenched & tempered) 42CrMo4 alloy steel (quenched & tempered) - High hardness & wear resistance
Vane Material Wear-resistant powder metallurgy alloy Wear-resistant powder metallurgy alloy - Self-lubricating & anti-seizure
PV7-1X/06-10RA01 <div class=Available Models
PV7-2X/20-25RA01KA0-10
PV7-1X/06-10RA01MA0-10
PV7-2X/20-25RA01MA0-05
PV7-1X/06-10RA01MA3-05
PV7-2X/20-25RA01MA0-10
PV7-1X/06-10RA01MA3-10
PV7-2X/20-25RA01MA3-05
PV7-1X/06-10RE01MA0-05
PV7-2X/20-25RA01MA3-10
PV7-1X/06-10RE01MA0-10
PV7-2X/20-25RE01MA0-05
PV7-1X/06-10RE01MA3-10
PV7-1X/06-10RG01MA0-05
PV7-2X/20-25RE01MA3-05
PV7-1X/06-10RG01MA0-10
PV7-2X/20-25RE01MA3-10
PV7-1X/06-10RG01MA3-10
PV7-1X/06-14RE01MA3-07
PV7-1X/06-14RA01MA0-04
PV7-1X/06-14RG01MA0-07
PV7-1X/06-14RA01MA0-07
PV7-2X/20-20RA01MA0-05
PV7-1X/06-14RA01MA3-04
PV7-2X/20-20RA01MA0-10
PV7-1X/06-14RA01MA3-07
PV7-2X/20-20RA01MA3-05
PV7-1X/06-14RE01MA0-04
PV7-2X/20-20RA01MA3-10
PV7-1X/06-14RE01MA0-07
PV7-2X/20-20RE01KA0-10
PV7-1X/06-14RE01MA3-04
Frequently Asked Questions
How to judge whether the PV7 series pump has internal leakage?

Signs of excessive internal leakage include insufficient system pressure, slow actuator movement, increased pump temperature rise, and decreased flow rate under rated speed and pressure; a pressure holding test can be performed for verification.

Can the PV7 series pumps be used in variable flow systems?

The PV7 series includes fixed-displacement models (PV7-1X) and variable-displacement models (PV7-2X); variable-displacement models can adjust the flow rate according to system demand by means of pressure compensation or flow compensation.

What is the maximum allowable speed of the PV7 series pumps?

The maximum rated speed varies with displacement; small-displacement models (≤20 cm³/rev) can reach up to 3000 rpm, while large-displacement models are generally limited to 1800-2500 rpm; refer to the product manual for specific models.

What oil cleanliness level is required for PV7 series pumps?

The recommended oil cleanliness level is ISO 4406 Class 18/15 or higher; regular oil filtration and tank cleaning are required to prevent wear of internal components caused by particle contaminants.

How to install the PV7 series pump correctly?

Mount the pump on a rigid base to reduce vibration; align the pump shaft with the motor shaft (coaxiality error ≤0.1 mm), use flexible couplings for connection, and ensure the suction port is lower than the oil level in the tank or use a charge pump for auxiliary suction in case of high installation positions.
